Shibuya Sight Ultima RC Pro G2 520-9-A Single Mount
The Shibuya Ultima RC Pro G2 520-9-A Single Mount is a professional sight model developed for classic bows. It offers precise and stable adjustment with 0.04 mm click accuracy, 107 mm vertical adjustment range, and a 9-inch polygonal carbon extension arm.
Shibuya Ultima RC Pro G2 520-9-A Single Mount Sight
The Shibuya Ultima RC Pro G2 520-9-A Single Mount Sight is a professional sight model developed to offer precise aiming and a wide adjustment range for classic bow users. Its single-mount design, 9-inch polygonal carbon extension arm, and precise click mechanism provide high control and stability in bow adjustments.
Precise Click and Wide Adjustment Range
0.04 mm click movement allows for precise elevation and windage adjustments. 107 mm vertical adjustment distance offers a wide adjustment range at different casting distances, while the 5.4 mm windage adjustment distance helps with precise horizontal adjustments.
The 233 mm (9 inch) long polygonal carbon extension arm offers a robust and stable structure. The click-ball extension locking system helps with repeatable adjustment of the extension arm position.
Stable and Backlash-Free Adjustment Mechanism
ZPE System eliminates backlash that can occur during tuning, providing a more stable tuning experience.
The X-Lock system provides precise and reliable windage adjustment thanks to its readjustable, zero-tolerance windage linkage.The elevation adjustment dial located at the bottom provides easy access, while the quick-release sight pin stopper system allows for quick adjustment of the sight pin without the need for any tools.
Professional Classic Bow Users
Weighing approximately 236 grams, the Shibuya Ultima RC Pro G2 520-9-A Single Mount meets the precision and adjustment control needs of professional classic bow users. Suitable for both right and left-handed use; Available in black, gunmetal, blue, and red color options.
Technical Specifications
- Model: Ultima RC Pro G2 520-9-A
- Product Type: Classic bow sight
- Mounting: Single Mount
- Extension Length: 233 mm / 9 inches
- Extension Material: Polygonal carbon
- Vertical Adjustment Distance: 107 mm
- Click Movement: 0.04 mm / click
- Wind Adjustment Distance: 5.4 mm
- Scope Pin Thread: No. 8-32
- Weight: Approximately 236 g (with sight pin)
- Usage: Right / Left hand
- Color Options: Black, gunmetal, blue and red
Box Contents
- Shibuya Ultima RC Pro G2 520-9-A Single Mount Sight
- Soft carrying case
- No. 10-24 screws
- Hex wrenches
- Blank tape
- Instruction manual
